Shows current gear number Indicates current gear from 1 to max of 6. as well as a neutral indicator. Detects the current gear faster than other gear indicators that use speedometer/tachometer signal. Display can be mounted anywhere Foreword: Congratulations on your purchase of a SEPP gear position indicator,This product will fit all Ducati fuel injected(EFI)motorcycles which have on board Diagnostic System connector. This connector is referred as DDS(Ducati Diagnostic System) in the Ducati manuals.Unlike other gear indicators available for your bike,this product connects to the diagnostic connector.It make the installation very sample. The unit reads data directly from the ECU, offering faster and more reliable readings than competing products.The display is auto learning,there are no button and no "programming wire" Know limitations;Your bike is not equipped with Gear Position Sensor. therefore determining the gear in use is only possible when the engine is running and the clutch is released. Instructions Guide: -Find the BLACK, 4-pole diagnostic connector (also called as DDA) under the seat or under the fuel tank -Detach the cover (cap) from the plug and connect the Gear Indicator plug. -Route the cable to the mounting location along the frame. -Peel the green plastic off from the back of the unit, and mount the display. -Secure the cable with the cable ties supplied. Set up: -You need to setup the module after installation. When ignition is turned on, the display counts backwards (6 to 1) indicating that the memory is clear. -Raise the rear wheel off the ground by using a stand, and start the engine in Neutral. (If you do not have a stand, you may setup the unit while riding. Find a long, straight road with light traffic.) -The display will blink 1.Select first gear, release the clutch, and keep the RPM above idle speed. The display is blinking faster while the unit is learning the gear. -When the display shows 2, select second gear. Repeat this process until all gears are thought (5 or 6). The unit is programmed and should indicate the gears correctly. Now, when ignition is turned on, the display counts forward (1 to 6) indicating that it is fully functional. Fitment: For Ducati Hyper motard All (2008-2019) For Ducati Hyper Strada All (2013-2019) For Ducati Monster 696 (ALL Year) For Ducati Monster 795 (ALL Year) For Ducati Monster 796 (ALL Year) For Ducati Monster 796 Corse Stripe (ALL Year) For Ducati Monster 797 (ALL Years) For Ducati Monster 821 (2014-2019) For Ducati Monster 1100 (ALL Year) For Ducati Monster 1100 EVO(ALL Years) For Ducati Monster 1200 (2014-2019) For Ducati Monster 1200S (2014-2019) For Ducati Monster 1200R (ALL Years) For Ducati Monster diesel (2012-2013) For Ducati Scrambler 400 (2016-2019) For Ducati Scrambler 800 (2015-2019) For Ducati Scrambler 1000 (2018-2019) For Ducati Scrambler 1100 (2018-2019) For Ducati Desmosedici RR (2008) For Ducati Supersport 937 (2017-2019) For Ducati Supersport 937S (2017-2019) For Ducati Superbike 848 (2008-2013) For Ducati Superbike 1098 (2009) For Ducati Superbike 1198 (2009-2019) For Ducati Streetfighter (2009-2019) (If you encounter any questions, please be sure to contact me first, please do not leave negative comments first, I very much hope to answer your questions, thank you)
