1.Integrated with the mighty function of the for + and for +ramps 1.4 kit, The GT2560 can not only take full place the them on respect of both software and hardware, but also features compact size, more convenient connection, and more stable. 2. Adopt ATmega2560 as the main control chip, coupled with the high-performance USB serial converter FT232RQ. 3. The power pack: operating voltage is 12V-24V; double power supply design feeds for heatbed and logical part separately. The current is 15A for heatbed and 10A for other parts. 4. The main circuit adopts SMD fuse tube, the diode added to the power port can provide reverse protection to the whole circuit, in addition, the 5V USB is USB port protected with 500mA Recoverable fuse. 5. 3 12v fan output and one PWM output for LED or other lighting equipment. 6. 3 55Amp MOSFET (with LED indicator, the actual output is restricted by the PCB board and the connector), all 3 MOSFET are equipped with heat sink to sufficient heat dissipation and stable operation. 7. Support 5 A4988 stepper drivers (3 for /Z axis, and 2 for extruders); the subdivision of stepper motor can be setup by dial switch, eliminating jumper caps, easier to operate. 8. 3 temperature sensor input (100k thermistor is recommended) 9. Extended LCD and SD card interface support both LCD2004 and LCD 12864, with which you can print without your PC. 10. The firmware is the prevalent , which is known for stability, usability, and high-performance. Colour:White Material:PCB+Plastic+Metal Size:109 x 78mm Package Contents: 1 x 3D Printer controller board Only the above package content, other products are not included. Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
